28 FT Diesel Orca (1638)

1638 Profile on Water Compressed.JPG
1638 Profile on Water Compressed.JPG 1638 Out of Harbor.jpeg 28 FT Diesel Orca Sketch Website.jpg

This design (plan) for a 28 FT Orca holds 120 gallons of fuel.

At 7,390 lbs. displacement with 120 gallons of fuel, at 315 HP, the boats projected speed is 33 knots.

Download drawing in PDF
  • Length Overall of Boat 28' 3" / 8.61 m LOA
  • Beam of Boat 10' 8" / 3.25 m Beam
  • Weight of Boat 6,275 lbs / 2,846 kg Weight
  • Price of Boat $3,990* Price

*The above price is for the construction plans and a onetime use of the CAD cutting files.

Hull 1638

Weight in table above is the weight of the uncut aluminum sheet and plate.
